Multihead Weigher Horizontal Premade Pouch Packaging Machine

Compact and high speed premade pouch packaging machine
SPEEDS UP TO 50 BPM

Machine Introduction

Multihead weigher horizontal premade pouch packaging machine is a favourable choice for snack packaging,candy packaging,biscuit packaging industry. Multihead weigher is also called combination weigher, it is a fully automatic ,high accuracy and efficient weighing machine.

Due to the mid speed of the horizontal doypack packaging machine, 10 and 14head weigher are most chosen, 1.6/2.5/3.0Liter weigher bucket version are the top rated.Depending on specific packaging requirement, you can choose multi head weigher according to required packaging speed, product target weigh etc.

Obviously the more head of a multihead weigher, the higher speed it can achieve. It is important to evaluate the required packaging capacity if you want to integrate the most efficient multihead weigher in the , Thus you have to consider if the combination weigher can be well synchronized with the horizontal premade pouch packaging system.As the system speed is a total performance,Rather then any singe one machine.

High capacity output and cost effective premade pouch packaging machine
Suitable choice for medium speed of premade pouch packaging in various industry upto 50pouch/min

Max Speed

50mpbm

Bag Size

Min
80mm W x 110 mm L

Max
260mm W x 380 mm L

Features

  • Food grade 304 stainless steel material
  • Compatible with almost all premade pouch style
  • Siemens PLC control
  • Great accessibility frame
  • Easy to set bag size on touch screen directly
  • Pouch detection – no filling, no sealing
  • Two step sealing process guarantees clean sealing

Options

  • Horizontal Bag feeder
  • Date printer
  • Zipper open device
  • Nitrogen filling device
  • Exhausting device
  • Hopper vibration
  • Bag-bottom vibration
  • Belowing bag function
  • Metal Detector
  • Check Weigher

Specifications

ModelWPT-160WPT-210WPT-260
Speed5-50bag/min5-50bag/min20-50bag/min
Power2kw2kw3.5kw
Bag sizeW:80-160mm
L:110-240mm
W:110-160mm
L:110-280mm
W:120-260mm
L:120-380mm
Packaging capacity10-200ml100-1000G50-1000ml
Air consumption0.7m3/min0.7m3/min0.7m3/min
Applicable bag style3/4 side sealing bag
paper bag,standup bag,
zipper bag
3/4 side sealing bag
paper bag,standup bag,
zipper bag
3/4 side sealing bag
paper bag,standup bag,
zipper bag

Auxiliary Machine​

Features

  • 10head & 14 head weigher, 1.6/2.5/L volume buckets
  • Teflon coating & dimple plate for anti-sticky
  • Linear feeder pan angle modification
  • Timming hopper
  • Waterproof protection

Options

  • Precise and high speed weighing machine
  • Strong vibration
  • Low noise running
  • Food grade 304ss contact parts
  • 99 storage setting
  • High sensitive color HMI
  • Photo eye detection

Video​

Pet food rotary pouch packing machine

Snacks rotary packing machine manufacturer

Industry​

coffee
sugar

Bag style

automate your packaging process - fast, accurate and efficient
